Performance Curve
Applications Fields
1. Suitable for transferring water without abrasive particles or other liquid whose properties are similar to water.
2. Widely used in solar boosting, water heater boosting, air energy boosting, various corollary equipment, etc.
Features
1. Stainless steel impeller, shaft 304
2. Specially designed for view of the hot water circulation
3. High quality mechanical seal, NSK bearing, improve the reliability of the product
Motor
1. Single-Phase 220V/50Hz
2. Motor: 2 pole asynchronous motor, copper wires, built-in thermal protector, fully closed fan cooling, continuous running
3. Protection: IP44
4. Insulation: F
Optional Available on Request
1. NSK bearing
2. Motor whose insulation class is F
3. Other voltage or frequency is 60Hz
Please feel free to get in touch with us, our highly trained sales
team is here to help you with any inquiry. We are opened 6 days
a week 8am to 5pm, and on Saturdays 9:30am to 1pm.
Performance Range
Max. Flow: 22m3/h
Max. Head: 480m
Application Limits
1. Max. ambient temperature < 40℃;
2. Sand content(in mass fraction)up to 0.01%;
3. hydrogen sulfide content up to 1.5mg/L, chloride ion content up to 400mg/L;
4. pH 6.5 to 8.5;
5. Maximum: 70m below the static water table.
Certificate
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Edible oil filled motor, stable& reliable running with pressure regulating membrane;
2. Single phase motor with built in B Grade oil proofed capacitor &thermal mode protector;
3. Available with cable with a motor plug, disassemble conveniently;
4. Available with pump casing with plug, 2~8 m3/hrs series with single stage floating impellers, 10~16m3/hrs series with integrated stage floating impellers;
5. Installation in 4" or larger boreholes;
Optional Available On Request
Oil chamber is available with brass or SS304; Discharge chamber, Inlet parts are available SS304.
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Edible oil filled motor, stable& reliable running with pressure regulating membrane;
2. Single phase motor with built in B Grade oil proofed capacitor &thermal mode protector;
3. Available with cable with a motor plug, disassemble conveniently;
4. Available with pump casing with plug, 2~8 m3/hrs series with single stage floating impellers, 10~16m3/hrs series with integrated stage floating impellers;
5. Installation in 4" or larger boreholes;
Optional Available On Request
Oil chamber is available with brass or SS304; Discharge chamber, Inlet parts are available SS304.
